Allen Bradley PanelView HMI 2711P-RDB7C PVP6 700 TOUCH/ KEYPAD LED DISPLAY MODUL
Okay, let's take a look at the PVP6 700 TOUCH/ KEYPAD LED DISPLAY MODUL:
1. Product Name:
- PVP6 700 TOUCH/ KEYPAD LED DISPLAY MODUL
2. Description:
- This is a touchscreen and keypad LED display module from IFM Electronics.
- It is designed to provide a user interface for industrial automation and control applications.
3. Key Features:
- 7-inch color TFT touchscreen display
- LED backlit display with 800 x 480 pixel resolution
- Integrated capacitive touch functionality
- Keypad with 16 buttons for direct user input
- Mounting dimensions of 176 x 128 mm (6.9 x 5.0 inches)
4. Applications:
- The PVP6 700 TOUCH/ KEYPAD LED DISPLAY MODUL is suitable for a variety of industrial applications, including:
- Human-machine interface (HMI) for industrial control systems
- Operator interface panels
- Process visualization and monitoring
- Machine control and automation
5. Connectivity:
- The display module features an Ethernet interface for communication and integration with industrial control systems.
- It supports various industrial communication protocols, such as Modbus TCP/IP and EtherNet/IP.
6. Capabilities:
- 7-inch color TFT touchscreen display
- 800 x 480 pixel resolution
- Capacitive touch functionality for intuitive user input
- 16-button keypad for direct control and navigation
- Ethernet interface for communication and integration
- Supports industrial communication protocols like Modbus TCP/IP and EtherNet/IP
7. Compatibility:
- The PVP6 700 TOUCH/ KEYPAD LED DISPLAY MODUL is designed to be compatible with a wide range of industrial automation systems and control equipment.
- It can be easily integrated into various industrial control networks and architectures.
The key features of this display module are the 7-inch color TFT touchscreen, the integrated capacitive touch functionality, and the 16-button keypad. These features provide a versatile and user-friendly interface for industrial applications.
The Ethernet connectivity and support for industrial communication protocols allow for seamless integration with industrial control systems and automation networks.
The compact form factor and mounting dimensions make the PVP6 700 TOUCH/ KEYPAD LED DISPLAY MODUL suitable for integration into various industrial enclosures and control panels.
Overall, this display module from IFM Electronics offers a comprehensive solution for human-machine interface and process visualization in industrial automation and control applications.
Please let me know if you have any other questions!
Mechanical
| Width |
290 mm |
| Height |
193 mm |
| Depth |
55 mm |
| Weight, approx |
1.9 kg |
| Cutout dimensions |
167 x 264 mm |
Electrical
| Number of pixels, vertical |
480 |
| Number of pixels, horizontal |
640 |
| Display size |
6.5 inch |
| Luminance |
300 cd/m2 (Nits) |
| Input voltage |
85...264V AC |
| Backlight |
CCFL, 50000 hours life, minimum |
| Operator input |
Keypad, touch |
| Power consumption |
70 W max (2.9 A at 24V DC), 39 W typical (1.6 A at 24V DC) |
| Operating force, keypad |
340 g |
| Line frequency |
47 Hz |
| Operating force, touch screen |
10 g |
| Remote power input voltage |
85...264V AC |
| Remote power consumption |
120VA maximum |
| External CompactFlash storage |
512 MB maximum |
| PCI slot available power supply, max |
11 W DC, 5 W AC |
| Touch screen |
Analog resistive |
| Actuation rating, touch screen |
1 million presses |
| Actuation rating, keypad |
1 million presses |
| LED indicators |
COMM (Green), fault (Red) |
| Battery life |
4 year minimum at 25 °C (77 °F) |
| Keypad function keys |
Function keys, numeric and navigation |
| Clock |
Battery-backed, +/-2 minutes per month |
| Application flash memory |
20 MB for logic modules, series A to D |
| Display type |
Color active matrix, thin-film transistor (TFT) with liquid crystal display (LCD) |
Environmental
| Operating temperature |
0 °C |
| Nonoperating temperature |
-25 °C |
| Shock |
Operating: 15 G at 11 ms |
| Degree of protection (IP) |
IP65 |
| Altitude, operating |
2000 m |
| List of degrees of protection (IP) |
IP54, IP65 |
| Heat dissipation |
240 BTU/hr |
| Relative humidity |
5...95% without condensation |
| Enclosure rating |
NEMA Type 12, 13, 4X (Indoor use only), IP54, IP65 |
| Vibration |
10...57 Hz, 0.012 peak-to-peak displacement, 57...500 Hz, 2 G peak acceleration |
Construction
| Display area |
132 x 99 mm |
| Description |
700 keypad and touch color display |
Documentation
| RESOURCE |
PUBLICATION NUMBER |
| Selection Guide |
VIEW-SG001 |
