Allen 2711P-T6C20A9 PanelView Plus 6 Graphic Terminal
Okay, let's take a closer look at the Allen-Bradley 2711P-T6C20A9 PanelView Plus 6 Graphic Terminal:
1. Product Name:
- Allen-Bradley 2711P-T6C20A9 PanelView Plus 6 Graphic Terminal
2. Description:
- This is a high-performance HMI (human-machine interface) terminal from Rockwell Automation's Allen-Bradley brand, part of the PanelView Plus 6 product line.
- It is designed to provide a comprehensive and user-friendly interface for industrial automation and control applications.
3. Key Features:
- 20-inch color TFT touchscreen display
- WUXGA resolution of 1920 x 1200 pixels
- Capacitive multi-touch technology for intuitive operation
- Integrated Ethernet and serial communication interfaces
- Runs on the Windows Embedded Standard 7 operating system
4. Applications:
- The 2711P-T6C20A9 PanelView Plus 6 Graphic Terminal is suitable for a wide range of industrial applications, including:
- Operator interface for machine control and automation
- Process visualization and monitoring
- HMI for complex industrial control systems
- Supervisory control and data acquisition (SCADA) systems
5. Connectivity:
- The graphic terminal features Ethernet, serial, and USB interfaces for communication and integration with industrial control systems.
- It supports various industrial communication protocols, such as Ethernet/IP, Modbus TCP/IP, and DF1.
6. Capabilities:
- 20-inch color TFT touchscreen display
- WUXGA resolution of 1920 x 1200 pixels
- Capacitive multi-touch technology for intuitive operation
- Integrated Ethernet and serial communication interfaces
- Runs on the Windows Embedded Standard 7 operating system
- Extensive library of pre-built HMI screens and templates
- Powerful graphics and visualization capabilities
7. Compatibility:
- The 2711P-T6C20A9 PanelView Plus 6 Graphic Terminal is designed to be compatible with Allen-Bradley and Rockwell Automation industrial control systems, including ControlLogix and CompactLogix PLCs.
- It can also be integrated into a wide range of industrial automation and control architectures.
The key features of this PanelView Plus 6 graphic terminal are the large 20-inch high-resolution touchscreen display, the capacitive multi-touch technology, and the powerful Windows Embedded Standard 7 operating system.
The high WUXGA resolution of 1920 x 1200 pixels provides a crisp and detailed visual interface, making it well-suited for applications that require extensive process visualization and monitoring.
The integrated Ethernet and serial communication interfaces, along with the support for various industrial protocols, enable seamless integration with a wide range of industrial control systems and automation networks.
The Windows Embedded Standard 7 operating system and the extensive library of pre-built HMI screens and templates offer a flexible and user-friendly platform for developing custom operator interfaces.
Overall, the Allen-Bradley 2711P-T6C20A9 PanelView Plus 6 Graphic Terminal is a high-performance and versatile HMI solution for industrial automation and control applications that require a large, high-resolution, and touch-enabled interface.
Please let me know if you have any other questions!
| Resolution |
320 x 240, 18-bit color graphics |
| Keypad function keys |
10 function keys (F1...F10) |
| Operator input |
Touch |
| Power consumption |
35VA maximum, 20VA typical |
| Display type |
Color active matrix, thin-film transistor (TFT) |
| Touch screen |
Analog resistive, 4-wire, Actuation: 1 million presses, Operating force: 10...110 g |
| Operating system |
Windows CE 6.0 operating system with extended features/file viewers |
| Backlight |
White LED, Not replaceable, 25,000 hours minimum at 25 °C (77 °F) |
| Keypad description |
Stainless-steel membrane, Numeric, navigation and function keys, Actuation: 1 million presses, Operating force: 340 g |
| Software |
FactoryTalk view machine edition software, version 6.10 or later, FactoryTalk viewpoint software is not supported on the 400 and 600 terminals |
| Input voltage |
100...240V AC, 50...60 Hz |
| Secure Digital (SD) card slot |
Hot-swappable card slot supports 1784-SDx and 1784-SDHCx SD cards for transferring files, upgrading firmware, or logging data |
| Battery (real-time clock) |
Battery-backed clock timestamps critical data, accuracy is ±2 minutes per month, Battery life: 4 year min at 25 °C (77 °F), Field-replaceable: cat. no. 2711P-RY2032 or equivalent CR2032 coin-cell lithium battery |
| USB ports |
One USB host ports for connecting a USB mouse, keyboard, printer, and USB flash drives that are hot swappable, One USB device port for connecting a host personal computer |
| Communication ports |
RS-232, 1 USB host, 1 USB device port (catalog numbers with the number 5, for example, 2711P-B4C5D8), Ethernet (10/100 Mbps, Auto-MDI/MDI-X), RS-232, 1 USB host, 1 USB device port (catalog numbers with the number 20, for example, 2711P-B4C20D8) |
